USED 2004 Chevrolet Avalanche 1500 5dr Crew Cab 130" WB 4WD Z71
Vin: 3GNEK12T24G118749
Stock #: 8749P
Mileage: 126,447
Internet Price:
$15,482
Est. Monthly Payment:
$257
Year:
2004
Make:
Chevrolet
Model:
Avalanche
Body Style:
1500 5dr Crew Cab 130" WB 4WD Z71
Exterior Color:
Black
Interior Color:
Dark Charcoal
Engine:
VORTEC 5300 V8 SFI
Transmission:
Automatic
Mileage:
126,447
Stock #:
8749P
VIN:
3GNEK12T24G118749
Fuel Economy:
14 city / 18 hwy
- Verified Equipment
- Standard Features
- Tech Specs
- Factory Equipment
- Consumer Information
- Factory Options
- PAINT, SOLID
- ENGINE, VORTEC 5300 V8 SFI295 HP [219.7 kW] @ 5200 rpm, 330 lb.-ft. [445.5 N-m] @ 4000 rpm)
Please Note: The included equipment is based on the dealership's bookout process and manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.
- Safety
- Air bags, frontal, driver and right front passenger, includes Passenger Sensing System (front passenger air bag status display on inside rearview mirror) (Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in a rear seat. See the Owner's Manual for more safety information.)
- Safety belts, 3-point, driver and front passenger, in all seating positions except center seating position in 1st row which are lap only
- Tether anchors, rear, lower, for child safety seat, LATCH anchorage system
- Exterior
- Bumper, front and rear, Dark Charcoal, step (Not available with (WBH) Without Body Hardware.)
- Body hardware, Dark Charcoal bodyside, front and rear fascia (Not available with (WBH) Without Body Hardware.)
- Door handles, color-keyed (Not available with (WBH) Without Body Hardware.)
- Fog lamps, front, round, halogen
- Mirrors, outside rearview, power folding, power adjustable, heated, color-keyed, driver side electrochromic (light-sensitive auto dimming), turn signal in glass, with ground illumination and curb-tilt (When (WBH) Without Body Hardware is ordered, Mirrors are Black. Curb-tilt feature requires (PDH) Driver Convenience Package or (UE1) OnStar.)
- Wipers, intermittent, front wet-arm with pulse washers
- Midgate, foldable door between cargo box and cab, removable and stowable rear window
- Cargo cover, rear, rigid, 3-piece composite, stowable onboard
- Pickup bed mat, Black rubber
- Storage box, integrated top box with locks and lights
- Interior
- Seats, rear cloth 60/40 split-bench, flat folding, 3-passenger
- Driver Information Center, includes trip odometer, tire pressure monitor, passenger seat belt reminder and message center (monitors numerous systems depending on vehicle equipment including low fuel, transmission temperature, engine coolant, security, oil pressure, and oil change.) (With UK3 steering wheel mounted radio controls, Radio and Driver Information Center (DIC) includes trip computer (personal and business trip odometer, range, average speed, average fuel economy, trip timers, 15-day vehicle speed history and annual mileage) and programmable personalized features (Full functionality included and only available when (PDH) Driver Convenience Package or (UE1) OnStar is ordered.)
- Instrumentation, analog, includes speedometer, fuel level, voltmeter, engine temperature, oil pressure and tachometer
- Warning tones, headlamp on, key-in-ignition, driver and right front passenger safety belt unfasten, turn signal on
- Defogger, rear-window, electric
- Steering column, Tilt-Wheel, adjustable, includes brake/transmission shift interlock
- Steering wheel, leather-wrapped rim, Black
- Theft-deterrent system, PASSlock II
- Cruise control, electronic with set and resume speed, includes telltale in instrument panel cluster
- Sound system feature, 6-speakers
- Headliner, Shale-colored cloth, with matching retainer moldings
- Assist handles, front passenger and outboard rear seats
- Cupholders, dual, front, rear and tailgate
- Mirror, inside rearview, electrochromic (light-sensitive auto dimming), 8-point compass and outside temperature indicator
- Visors, padded, Shale-colored, driver and passenger side with cloth trim, extenders and lighted vanity mirrors
- Mechanical
- Engine, Vortec 5300 V8 SFI (295 HP [219.7 kW] @ 5200 rpm, 330 lb.-ft. [445.5 N-m] @ 4000 rpm) (Requires C*15936 Models)
- Air cleaner, high-capacity
- Transfer case, electronic Autotrac, includes push-button controls (Requires CK*5936 Models.)
- Rear axle, 3.73 ratio
- Four wheel drive
- Battery, heavy-duty, 600 cold-cranking amps, includes rundown protection and retained accessory power
- Alternator, 105 amps
- Trailering wiring harness, 7-wire
- Trailering equipment, heavy-duty, includes trailering hitch platform, 7-pin wiring connector and housing, trailer brake pre-wire harness and 7-way to 4-way adapter
- Recovery hooks, 2 front, integrated into front bumper
- Suspension, front, independent torsion bar
- Suspension, rear, multi-link with coil springs (Requires C*15936 Models.)
- Skid Plate Package, includes aluminum front underbody shield starting behind front bumper and running to 1st cross-member, protecting front underbody, oil pan, differential case and transfer case, frame-mounted shields
- GVWR, 7000 lbs. (3175 kg) (Requires CK15936 Models.)
- Tire, spare, full-size, 16" (40.6 cm) steel wheel located at rear underbody of vehicle, blackwall
- Spare tire, lockable, outside spare, winch-type mounted under frame at rear, with matching tire
- Steering, power
- Key, single, 2-sided
Please Note: These features are based on the manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.
- Chassis
- Frame
- Frame Type: Ladder
- Tires
- Front Tire Size: P265/70R17
- Rear Tire Size: P265/70R17
- Spare Tire Size: 16"
- Front Tire Capacity: 2134 lbs
- Rear Tire Capacity: 2134 lbs
- Spare Tire Capacity: 2134 lbs
- Revolutions/Mile @ 45 mph - Front: - TBD - Rev/Mile
- Revolutions/Mile @ 45 mph - Rear: - TBD - Rev/Mile
- Revolutions/Mile @ 45 mph - Spare: - TBD - Rev/Mile
- Brakes
- Brake Type: Pwr
- Brake ABS System: 4-Wheel
- Disc - Front (Yes or ): Yes
- Disc - Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness: 12.0 x 1.1 in
- Rear Brake Rotor Diam x Thickness: 12.9 x 1.2 in
- Wheels
- Front Wheel Size: 17 x 7 in
- Rear Wheel Size: 17 X 7 in
- Spare Wheel Size: 16 in
- Front Wheel Material: Aluminum
- Rear Wheel Material: Aluminum
- Spare Wheel Material: Steel
- Steering
- Steering Type: Pwr
- Steering Ratio (:1), On Center: 15.8
- Steering Ratio (:1), At Lock: 3.2
- Turning Diameter - Curb to Curb: 43.3 ft
- Turning Diameter - Wall to Wall: - TBD - ft
- Fuel Tank
- Fuel Tank Capacity, Approx: 31 gal
- Suspension
- Suspension Type - Front: Indep Torsion Bar
- Suspension Type - Rear: Multi-Link
- Spring Capacity - Front: 3800 lbs
- Spring Capacity - Rear: 4000 lbs
- Axle Type - Front: Independent
- Axle Type - Rear: Semi-Floating
- Axle Capacity - Front: 3925 lbs
- Axle Capacity - Rear: 4000 lbs
- Shock Absorber Diameter - Front: 46 mm
- Shock Absorber Diameter - Rear: 46 mm
- Stabilizer Bar Diameter - Front: 1.12 in
- Stabilizer Bar Diameter - Rear: 1.12 in
- Trailering
- Dead Weight Hitch - Max Trailer Wt.: 5000 lbs
- Dead Weight Hitch - Max Tongue Wt.: 600 lbs
- Wt Distributing Hitch - Max Trailer Wt.: 8000 lbs
- Wt Distributing Hitch - Max Tongue Wt.: 800 lbs
- Fifth Wheel Hitch - Max Trailer Wt.: N/A lbs
- Fifth Wheel Hitch - Max Tongue Wt.: N/A lbs
- Weight Information
- Gross Axle Wt Rating - Front: 3800 lbs
- Gross Axle Wt Rating - Rear: 4000 lbs
- Curb Weight - Front: 2941 lbs
- Curb Weight - Rear: 2560 lbs
- Gross Vehicle Weight Rating Cap: 7000 lbs
- Frame
- Vehicle
- Vehicle
- Country of Origin: Mexico Chevrolet MPV
- Vehicle
- Dimensions
- Exterior Dimensions
- Wheelbase: 130.0 in
- Length, Overall w/o rear bumper: 220.8 in
- Width, Max w/o mirrors: 79.8 in
- Height, Overall: 74.5 in
- Overhang, Front: 38.8 in
- Overhang, Rear w/o bumper: 52.9 in
- Ground to Top of Load Floor: 31.0 in
- Ground Clearance, Front: 8.8 in
- Ground Clearance, Rear: 8.8 in
- Interior Dimensions
- Front Head Room: 40.7 in
- Front Leg Room: 41.3 in
- Front Shoulder Room: 65.2 in
- Front Hip Room: 61.4 in
- Second Head Room: 38.6 in
- Second Leg Room: 38.9 in
- Second Shoulder Room: 65.2 in
- Second Hip Room: 62.0 in
- Cargo Area Dimensions
- Cargo Box Length @ Floor: 63.0 Min, 97.6 Max in
- Cargo Box Width @ Top, Rear: 50.0 in
- Cargo Box Width @ Floor: 50.0 in
- Cargo Box Width @ Wheelhousings: 50.0 in
- Cargo Box (Area) Height: 22.5 in
- Tailgate Width: - TBD - in
- Cargo Volume: 41.0 Min ft³
- Exterior Dimensions
- Powertrain
- Engine
- Engine Order Code: LM7
- Engine Type: Gas V8
- Displacement: 5.3L/327
- Fuel System: SFI
- SAE Net Horsepower @ RPM: 295 @ 5200
- SAE Net Torque @ RPM: 330 @ 4000
- Electrical
- Cold Cranking Amps @ 0° F (Primary): 600
- Transmission
- Drivetrain: 4-Wheel Drive
- Trans Order Code: M30
- Trans Type: 4
- Trans Description Cont.: Automatic w/OD
- First Gear Ratio (:1): 3.06
- Second Gear Ratio (:1): 1.63
- Third Gear Ratio (:1): 1.00
- Fourth Gear Ratio (:1): 0.70
- Reverse Ratio (:1): 2.29
- Trans Power Take Off: New Venture Gear NVG246
- Transfer Case Model: New Venture 246
- Cooling System
- Total Cooling System Capacity: 13.88 qts
- Engine
Please Note: These technical specifications are based on the manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.
- Safety
- Safety features
- Daytime Running Lights
- Automatic Headlights
- Integrated Turn Signal Mirrors
- Tow Hooks
- Air bag - frontal
- Driver Air Bag
- Passenger Air Bag
- Passenger Air Bag Sensor
- Safety features
- Chassis
- Tires
- Tire Pressure Monitor
- Brakes
- ABS
- 4-Wheel Disc Brakes
- Wheels
- Aluminum Wheels
- Steering
- Power Steering
- Trailering
- Tow Hitch
- Tires
- Seating
- Seats
- Power Driver Seat
- Rear Bench Seat
- Seats
- Exterior
- Pickup box
- Bed Liner
- Tire - rear
- Tires - Rear On/Off Road
- Tire - front
- Tires - Front On/Off Road
- Tire - spare
- Conventional Spare Tire
- Pickup box
- Powertrain
- Fuel
- Gasoline Fuel
- Engine
- 8 Cylinder Engine
- Drivetrain
- Four Wheel Drive
- Differential
- Locking/Limited Slip Differential
- Transmission
- 4-Speed A/T
- A/T
- Transmission Overdrive Switch
- Fuel
- Accessories
- Audio
- AM/FM Stereo
- CD Player
- Locks
- Keyless Entry
- Power Door Locks
- Window
- Rear Defrost
- Power Windows
- Privacy Glass
- Mirrors
- Heated Mirrors
- Power Mirror(s)
- Auto-Dimming Rearview Mirror
- Driver Vanity Mirror
- Passenger Vanity Mirror
- Driver Illuminated Vanity Mirror
- Passenger Illuminated Visor Mirror
- Power Folding Mirrors
- Floor mats
- Floor Mats
- Convenience
- Security System
- Cruise Control
- Adjustable Steering Wheel
- Intermittent Wipers
- Fog Lamps
- Steering Wheel Audio Controls
- Power Outlet
- Immobilizer
- Front Reading Lamps
- Rear Reading Lamps
- Leather Steering Wheel
- Trip Computer
- Telematics
- Cargo Shade
- Air conditioning
- Multi-Zone A/C
- A/C
- Audio
Please Note: These options are based on the manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.
- Factory Warranty
- Basic Years: 3
- Basic Miles/km: 36,000
- Drivetrain Years: 3
- Drivetrain Miles/km: 36,000
- Corrosion Years: 6
- Corrosion Miles/km: 100,000
- Roadside Assistance Years: 3
- Roadside Assistance Miles/km: 36,000
- Crash Test Results
- Frontal Driver: * * *
- Frontal Passenger: * * * *
- Side Driver: No Test
- Side Rear Passenger: No Test
- Crash Test Note: Results based on a 35 MPH frontal crash and 38.5 MPH side crash. Results are reported in a range of one to five stars, with five stars indicating the best crash protection for vehicles within the same weight class. This test used driver and passenger belts and airbags.
Please Note: This information is based on the manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.
