USED 2009 Chevrolet Express Passenger RWD 3500 155"
Vin: 1GAHG39K391165979
Stock #: 165979
Mileage: 111,130
Internet Price:
$29,875
Est. Monthly Payment:
$494
Year:
2009
Make:
Chevrolet
Model:
Express Passenger
Body Style:
RWD 3500 155"
Exterior Color:
Summit White
Interior Color:
TAN
Engine:
VORTEC 6.0L V8 SFI
Transmission:
Automatic
Mileage:
111,130
Stock #:
165979
VIN:
1GAHG39K391165979
- Verified Equipment
- Standard Features
- Tech Specs
- Factory Equipment
- Consumer Information
- Factory Options
- ENGINE, VORTEC 6.0L V8 SFI(319 hp [237.9 kW] @ 4600 rpm, 367 lb-ft of torque [495.5 N-m] @ 4400 rpm)
- SUMMIT WHITE
Please Note: The included equipment is based on the dealership's bookout process and manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.
- Safety
- StabiliTrak, traction assistance and vehicle stability enhancement system
- Brake/transmission shift interlock for automatic transmissions
- Door beams, steel-side
- Daytime Running Lamps
- Air bags, frontal, driver and right-front passenger (Includes passenger-side air bag deactivation switch for models with (C6P) 8600 lbs. (3901 kg) GVWR and above. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. Always use safety belts and the correct child restraints for your childs age and size, even in vehicles equipped with air bags. Children are safer when properly secured in a rear seat. See the vehicles Owners Manual and child safety seat instructions for more safety information.)
- Air bags, head/side-curtain provides coverage for first 3-rows only. Enhanced-technology glass is provided for the fourth and fifth rows when equipped with 12- and 15-passenger seating. (Head curtain side air bags are designed to help reduce the risk of head and neck injuries to front and rear seat occupants on the near side of certain side-impact collisions. Always use safety belts and the correct child restraints for your childs age and size, even in vehicles equipped with air bags. Children are safer when properly secured in a rear seat. See the vehicles Owners Manual and child safety seat instructions for more safety information.)
- Child seat anchors all three passenger rear seats have four anchors and two tethers
- Exterior
- Tires, front LT245/75R16E all-season, blackwall (Standard on *G23406, *G33406 and *G33706 models.)
- Tires, rear LT245/75R16E all-season, blackwall (Standard on *G23406, *G33406 and *G33706 models.)
- Tire, spare LT245/75R16E all-season, blackwall located at rear underbody of vehicle (Standard on *G23406, *G33406 and *G33706 models.)
- Body, standard
- Bumpers, front and rear painted Black with step-pad (Not available when ordered with (V37) front and rear chrome bumpers.)
- Grille, Black composite with single rectangular halogen headlamps
- Headlamps, halogen
- Mirrors, outside manual, Black
- Glass, Solar-Ray deep-tinted (all windows except light-tinted glass on windshield and driver- and front passenger-side glass)
- Glass, swing-out side door windows
- Glass, swing-out rear cargo door windows
- Glass, enhanced-technology, rearmost side windows. 3-layer special glass is designed to help reduce the risk of ejection during a crash. (Standard on *G23406, *G33406 and *G33706 models with 12- and 15-passenger seating. Not available with 8-passenger seating.)
- Glass, full-body window package (Includes (A18) swing-out rear cargo door glass and (A19) swing-out side door window glass.)
- Wipers, front intermittent wet-arm with pulse washers
- License plate kit, front
- Door, swing-out passenger-side, 60/40 split
- Interior
- Console, engine cover with open storage bin
- Cup holders, 3 on engine console cover
- Floor covering, full-length Black rubberized-vinyl
- Steering wheel steel sleeve column with theft-deterrent locking feature, Black
- Instrumentation, analog with speedometer, odometer with trip odometer, fuel level, voltmeter, engine temperature and oil pressure
- Oil life monitor
- Warning tones, headlamp on and key-in-ignition
- Compass, 8-Point digital located in the Driver Information Center (Included and only available with (C69) rear air conditioning.)
- Theft-deterrent system, vehicle, PASS-Key III
- Heater, rear auxiliary (Included with (C69) rear air conditioning. Standard on *G33706 models only.)
- Defogger, front and side windows
- Mirror, inside rearview manual day/night
- Headliner, cloth
- Assist handle, front passenger
- Lighting, interior with 2 dome lights defeat switch and door handle-activated switches
- Mechanical
- Engine, Vortec 6.0L V8 SFI (319 hp [237.9 kW] @ 4600 rpm, 367 lb-ft of torque [495.5 N-m] @ 4400 rpm) (Standard on *G23406, *G33406 or *G33706 models. Includes external engine oil cooler. Reference the Engine/Axle page for availability. Horsepower and torque may vary based on whether (FE9) Federal emissions requirements or (YF5) California emissions requirements are ordered.)
- Rear axle, 3.73 ratio (Standard on *G23406 and *G33*06 models. Available on **13406 models.)
- Rear-wheel drive
- Battery, 600 cold-cranking amps, maintenance-free with rundown protection and retained accessory power
- Alternator, 145 amps (Included with (C69) rear air conditioning.)
- Frame, ladder-type
- Suspension, front independent with coil springs and stabilizer bar (Standard and only available on *G***06 models.)
- Suspension, rear hypoid drive axle with multi-leaf springs
- GVWR, 9600 lbs. (4354 kg) (Standard on *G33*06 models. Reference the Engine/Axle page for availability.)
- Steering, power
- Brakes, 4-wheel antilock, 4-wheel disc
- Fuel tank capacity, mid-frame and approximately 31 gallons (117.3L)
- Exhaust, aluminized stainless-steel muffler and tailpipe
Please Note: These features are based on the manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.
- Chassis
- Frame
- Frame Type: Ladder-type
- Tires
- Front Tire Order Code: XHH
- Rear Tire Order Code: YHH
- Spare Tire Order Code: ZHH
- Front Tire Size: LT245/75R16E
- Rear Tire Size: LT245/75R16E
- Spare Tire Size: LT245/75R16E
- Front Tire Capacity: 2205 lbs
- Rear Tire Capacity: 3042 lbs
- Spare Tire Capacity: - TBD - lbs
- Revolutions/Mile @ 45 mph - Front: - TBD - Rev/Mile
- Revolutions/Mile @ 45 mph - Rear: - TBD - Rev/Mile
- Revolutions/Mile @ 45 mph - Spare: - TBD - Rev/Mile
- Brakes
- Brake Type: Pwr
- Brake ABS System: 4-Wheel
- Disc - Front (Yes or ): Yes
- Disc - Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness: 12.8 x 1.5 in
- Rear Brake Rotor Diam x Thickness: 13 x 1.14 in
- Wheels
- Front Wheel Size: 16 x - TBD - in
- Rear Wheel Size: 16 x - TBD - in
- Spare Wheel Size: 16 x - TBD - in
- Front Wheel Material: Steel
- Rear Wheel Material: Steel
- Spare Wheel Material: Steel
- Steering
- Steering Type: Pwr Rack-&-Pinion
- Steering Ratio (:1), On Center: 17.2
- Steering Ratio (:1), At Lock: 17.2
- Turning Diameter - Curb to Curb: 54.5 ft
- Turning Diameter - Wall to Wall: - TBD - ft
- Fuel Tank
- Fuel Tank Capacity, Approx: 31 gal
- Fuel Tank Location: Mid Inboard Rail
- Suspension
- Suspension Type - Front: Coil springs
- Suspension Type - Rear: Multi-leaf
- Spring Capacity - Front: 4300 lbs
- Spring Capacity - Rear: 6084 lbs
- Axle Type - Front: Independent
- Axle Type - Rear: Semi-Floating
- Axle Capacity - Front: 4300 lbs
- Axle Capacity - Rear: 6084 lbs
- Axle Ratio (:1) - Rear: 3.73
- Shock Absorber Diameter - Front: - TBD - mm
- Shock Absorber Diameter - Rear: - TBD - mm
- Stabilizer Bar Diameter - Front: 1.38 in
- Trailering
- Dead Weight Hitch - Max Trailer Wt.: 5000 lbs
- Dead Weight Hitch - Max Tongue Wt.: 500 lbs
- Wt Distributing Hitch - Max Trailer Wt.: 7400 lbs
- Wt Distributing Hitch - Max Tongue Wt.: 1110 lbs
- Fifth Wheel Hitch - Max Trailer Wt.: N/A lbs
- Fifth Wheel Hitch - Max Tongue Wt.: N/A lbs
- Weight Information
- Gross Axle Wt Rating - Front: 4300 lbs
- Gross Axle Wt Rating - Rear: 6084 lbs
- Curb Weight - Front: 2937 lbs
- Curb Weight - Rear: 3312 lbs
- Gross Vehicle Weight Rating Cap: 9600 lbs
- Gross Combined Wt Rating: 14000 lbs
- Frame
- Vehicle
- Vehicle
- Rear Door Type: Panel
- Country of Origin: United States Chevrolet Active
- Vehicle
- Dimensions
- Exterior Dimensions
- Wheelbase: 155.0 in
- Length, Overall w/rear bumper: 244.1 in
- Width, Max w/o mirrors: 79.4 in
- Height, Overall: 82.0 in
- Overhang, Front: 39.7 in
- Overhang, Rear w/bumper: 49.4 in
- Ground to Top of Load Floor: 27.3 in
- Ground Clearance, Front: 8.1 in
- Ground Clearance, Rear: 7.7 in
- Rear Door Opening Height: 49.4 in
- Rear Door Opening Width: 57.0 in
- Side Door Opening Height: 47.9 in
- Step Up Height - Front: 19.3 in
- Step Up Height - Side: 20.0 in
- Interior Dimensions
- Front Head Room: 40.2 in
- Front Leg Room: 41.3 in
- Front Shoulder Room: 68.8 in
- Front Hip Room: 65.5 in
- Cargo Area Dimensions
- Cargo Area Length @ Floor to Console: 173.6 in
- Cargo Area Length @ Floor to Seat 1: 147.8 in
- Cargo Area Length @ Floor to Seat 4: 45.6 in
- Cargo Area Width @ Beltline: - TBD - in
- Cargo Box Width @ Wheelhousings: 50.5 in
- Cargo Box (Area) Height: 51.9 in
- Cargo Volume to Seat 1: 252.6 ft³
- Cargo Volume to Seat 2: - TBD - ft³
- Exterior Dimensions
- Powertrain
- Engine
- Engine Order Code: LY6
- Engine Type: Gas V8
- Displacement: 6.0L/364
- Fuel System: SFI
- SAE Net Horsepower @ RPM: 319 @ 4600
- SAE Net Torque @ RPM: 367 @ 4400
- Engine Oil Cooler: Yes
- Electrical
- Maximum Alternator Capacity (amps): 145
- Maximum Alternator Watts: - TBD -
- Transmission
- Drivetrain: Rear Wheel Drive
- Trans Order Code: MT1
- Trans Type: 4
- Trans Description Cont.: HD Automatic w/OD
- First Gear Ratio (:1): 2.48
- Second Gear Ratio (:1): 1.48
- Third Gear Ratio (:1): 1.00
- Fourth Gear Ratio (:1): 0.75
- Reverse Ratio (:1): 2.07
- Trans Power Take Off: N/A
- Cooling System
- Total Cooling System Capacity: 14.4 qts
- Engine
Please Note: These technical specifications are based on the manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.
- Safety
- Air bag - side
- Front Head Air Bag
- Rear Head Air Bag
- Safety features
- Daytime Running Lights
- Traction Control
- Stability Control
- Air bag - frontal
- Driver Air Bag
- Passenger Air Bag
- Air bag - side
- Chassis
- Tires
- Tire Pressure Monitor
- Brakes
- ABS
- 4-Wheel Disc Brakes
- Wheels
- Steel Wheels
- Steering
- Power Steering
- Tires
- Seating
- Seats
- 3rd Row Seat
- Bucket Seats
- Seats
- Exterior
- Tire - rear
- Tires - Rear All-Season
- Tire - front
- Tires - Front All-Season
- Tire - spare
- Conventional Spare Tire
- Tire - rear
- Powertrain
- Fuel
- Gasoline Fuel
- Engine
- 8 Cylinder Engine
- Drivetrain
- Rear Wheel Drive
- Transmission
- 4-Speed A/T
- A/T
- Transmission Overdrive Switch
- Fuel
- Accessories
- Audio
- AM/FM Stereo
- Window
- Privacy Glass
- Mirrors
- Driver Vanity Mirror
- Passenger Vanity Mirror
- Passenger Illuminated Visor Mirror
- Convenience
- Cruise Control
- Adjustable Steering Wheel
- Intermittent Wipers
- Power Outlet
- Immobilizer
- Front Reading Lamps
- Trip Computer
- Air conditioning
- A/C
- Rear A/C
- Audio
Please Note: These options are based on the manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.
- Factory Warranty
- Basic Years: 3
- Basic Miles/km: 36,000
- Drivetrain Years: 5
- Drivetrain Miles/km: 100,000
- Corrosion Years: 6
- Corrosion Miles/km: 100,000
- Roadside Assistance Years: 5
- Roadside Assistance Miles/km: 100,000
Please Note: This information is based on the manufacturer's default configuration for this particular vehicle's type (year/make/model/style) which may vary slightly from the actual vehicle in stock. See salesperson to verify accuracy prior to purchase.
